ROCKWELL 85.50″ Square Galvanized Trailer Axle (3,500 lb.)

Introducing the Rockwell American universal replacement axle, designed specifically for trailers. This galvanized axle stock weldment is engineered for durability and performance.

Key Features:

• Material: Galvanized axle stock for enhanced corrosion resistance.
• Wear Protection: Equipped with a stainless steel wear sleeve for longevity.
• Maintenance: Features super lube grease zerks for easy lubrication.
• Wheel Hubs & Bearings: Sold separately to customize your setup.

Specifications:

• Axle Type: 2″ x 2″ Square – Galvanized
• Load Rating: 3,500 lbs
• Overall Length: 90″ (End of Spindle to End of Spindle)
• Spring Center: Recommended at 69.75″ – 73.75″
• Hub Face: 85.50″
• Brake Flange (Outside): 79″
• Hub Type: 5 bolt (Not Included)
• Spindle Size: 1-3/8″ x 1-1/16″
• Camber: 1° Per Side, welded at spindles

Important Note:

Axles are shipped without spring seat holes or drain hole. It is the customer’s responsibility to drill spring holes according to your trailer’s specifications, as well as a 5/16″ drain hole. Please be advised that once holes have been drilled, axles are non-returnable.

Upgrade your trailer’s performance with the ROCKWELL 85.50″ Square Galvanized Trailer Axle!
